LH a DLH

LH

Performance

  • Stirring speed: 50 - 2000 rpm
  • Stirring volume max (H2O): 40 liters
  • Max viscosity: 50.000 (mPa*s)*
  • Torque max: 80 Ncm
  • Allowed room temperature: 0-40 °C


Technical parameters:

  • Construction material: technopolymer and epoxy painted aluminum alloy
  • Visualization of effective speed: graduated scale
  • Chuck range: 1 - 10 mm
  • Electronic protection rating CEI EN 60529: IP 40
  • Power: 190 W
  • Weight: 2,9 Kg
  • Dimensions (WxHxD): 80x230x196 mm



DLH

Performance

  • Stirring speed: 50 - 2000 rpm
  • Stirring volume max (H2O): 40 liters
  • Max viscosity: 50.000 (mPa*s)*
  • Torque max: 80 Ncm
  • Allowed room temperature: 0-40 °C


Technical parameters:

  • Construction material: technopolymer and epoxy painted aluminum alloy
  • Visualization of effective speed: display LCD
  • Chuck range: 1 - 10 mm
  • Electronic protection rating CEI EN 60529: IP 40
  • Power: 190 W
  • Weight: 3,0 Kg
  • Dimensions (WxHxD): 80x230x196 mm


Comparison Table Solutions for Overhead Stirring.

PDF for download
